Draytek Vigor 2700 Router
Draytek Vigor 2700Ge  Draytek Vigor 2700V(2S)  Draytek Vigor 2700VG(2S)
Draytek Vigor 2700V(2S,1L)   Draytek Vigor 2700VG(2S,1L)

• ADSL/ADSL2+ Router

• Compatible with ADSL, ADSL Max, ADSL2 &, ADSL2+

• Universal Plug'n'Play (uPnP)

• Firewall - Help protect your PCs from external attacks

• NAT Port redirection

• 4-Port 10/100BaseT Autosensing Ethernet Switch

• Dynamic DNS Posting, compatible with popular DDNS providers

• Easy configuration, monitoring & control from web-interface

• DNS Proxy/Cache & DHCP Server

• Dial-Out VPN Facilities

• Wireless LAN Interface ('G' models only)

• VoIP Phone Ports ('V' models only)



The Draytek Vigor 2700 is an ADSL2/2+ enabled integrated access device.  With downstream speed up to 12Mbps (ADSL2) or 24Mbps (ADSL2+), the Vigor router provides exceptional bandwidth for Internet access. The available bandwidth depends on the Internet Service Provider.  The Draytek Vigor 2700 targets requirements for residential, SOHO (Small Office and Home Office) and business users.

To secure your network, the Draytek Vigor 2700 router provides an advanced firewall with advanced features, such as NAT with multi VPN pass-through, Stateful Packet Inspection (SPI) to offer network reliability by detecting and prohibiting malicious penetrating packets or DoS attacks, user-configurable web filtering for parental control against network abuse etc.

The Draytek Vigor 2700 G model is embedded with an 802.11g compliant wireless module which provides wireless LAN access with data rate as much as 54Mbps. As for data privacy of wireless network, the Vigor router can encode all transmissions data with standard WEP and industrial strength WPA2 (IEEE 802.11i) encryption. Additional features include Wireless Client List and MAC Address Control for maintaining control over user?s authorization in your network, and Hidden SSID for being invisible to outside intruders scanning.

The Draytek Vigor 2700 provides easy Internet-sharing of your broadband connection
Draytek Vigor 2700 offers a robust firewall to help protect your network from external attacks



Draytek Vigor 2700 Series Specification

• ADSL Interface compliant with :

  • ADSL, ADSLMax, ADSL2, ADSL2+, Annex A & Annex M

• Routing Protocls :

  • Internet Protocols : PPP (RFC 1661), PPPoA (RFC2364), MPoA

  • LAN Protocols : ARP, Proxy ARP, IP, ICMP, IGMP, UDP, TCP

  • Authentication Protocols : PAP, CHAP, MS-CHAP

  • DNS Proxy & Cache

• Universal Plug'n'Play (uPnP) support

• SNMP Reporting Facilities

• Firewall Facilities :

  • Protection against DoS/DDos attacks & IP Anti-Spoofing

  • Default Port Blocking through NAT

  • User definable IP filters

  • URL Filter (block specific web sites)

  • Surfcontrol Web site Category Blocking (subject to subscription)

  • Block HTTP download of common harmful file types

  • Peer-to-Peer Software and Instant Messaging Blocking

• VPN Facilities (Dial-Out only)

  • Create up to two dial-out VPN tunnels to remote hosts

  • Support for PPTP with MPPE encryption over PPTP

  • Support for L2TP & IPSec with Pre-shared key

  • DES (56-bit key strength) & 3DES (168-bit key strength) encryption

  • AH (Authenticated Header) &

  • ESP (Encapsulated Payload) modes

  • SHA-1 and MD5 integrity algorithms

  • X.509 Client Certificate Support

  • Remote VPN compatible with other vendor firewalls/VPN devices including Cisco, Nokia, SonicWall, WatchGuard

  • VPN Passthrough for VPN client/server running behind the router

• Wireless LAN Features ('G' Models only)

  • 802.11b & 802.11g Compatibility

  • WEP & WPA Wireless Security & Encryption

  • WDS - Wireless Distribution System for expanding wireless networks

• VoIP Features ('V' Models only):

  • Phone Port for connecting a regular analogue or cordless phone

  • SIP Standard compliant, compatible with DRayTEL and many other VoIP services

  • Free Voice calls to any other compatible VoIP users worldwide

  • Switches automatically between your PSTN/POTS line and VoIP

  • Failover to PSTN in event of powercut/ADSL failure

  • Phone Book (Dialplan) and LCR Rules (Digit Map)

• Built-in Ethernet switch featuring :

  • Four port 10/100BaseT auto-selecting (IEEE802.3)

  • Automatic selection full/half duplex & straight/uplink modes

  • Dual-colour LED for each port to indicate operating speed

• NAT (Network Address Translation) featuring :

  • Port forwarding - individual ports (with optional translation) and ranges of ports

  • Open internal servers up for external access

  • Soft DMZ - For passthrough of all protocols/data to a single internal client

• DHCP Server - User configurable

• Easy to use Web-based User Interface, management with optional IP address restriction.

• Management Logging/Monitoring via :

  • Syslog

  • Web (Browser) based interface

  • Telnet Interface

• Flash-Upgradable memory for firmware upgrades/enhancements

• Support for local Class C LAN (up to 253 local users)

• Physical Characteristics:

  • Flash Upgradable firmware

  • Dimensions (mm) : L 218 x W 158 x H 36

  • Weight : 359 grams approx

  • Maximum Power Consumption : 10W approx

• Supported O/S : Windows 95, 98, ME, NT4, 2000, XP, Linux & MacOS8/9/X

• Warranty : Two (2) year manufacturer's RTB warranty

• Box contents : Router, UK PSU, Ethernet cable (1.8M), ADSL RJ11 Line cable (1.8M), Quickstart manual, Utility & Documentation CD-ROM, Wall-mounting screws, Aerial (Wireless models only)

Model	VPN	WLAN	DSL	VoIP
Draytek Vigor	2	-	ADSL2+	-
Draytek VigorG	2	802.11g	ADSL2+	-
Draytek Vigore	-	-	ADSL2+	-
Draytek VigorGe	-	802.11g	ADSL2+	-
Draytek VigorV(2S)	2	-	ADSL2+	2S
Draytek VigorVG(2S)	2	802.11g	ADSL2+	2S
Draytek VigorV(2S,1L)	2	-	ADSL2+	2S,1L
Draytek VigorVG(2S,1L)	2	802.11g	ADSL2+	2S,1L
