GDC SpectraComm 553 (SC 553) DSU Card
 076P016-001 076M016-001 076M016-010 076M016-011

Call us for Pre-sales and discount pricing

  301-924-7400 Support

GDC SpectraComm 553 (SC 553) DSU Card
 076P016-001 076M016-001 076M016-010 076M016-011

SpectraComm 553 (SC 553) DSU Card

SC 553 Key Features:

• Network Managed T1 / FT1 CSU/DSU
• Supports N x 56/64 kbps to 1.536 Mbps payload
• In-band SNMP management via various diagnostic control channels
• Optional DSX-1 cascade “drop and insert” port
• Local or remote management
• Auto configuration with SCM

The SpectraComm 553 is a rackmounted single channel T1 / FT1 CSU/DSU offering highly cost-effective, direct line-by-line access to the T1 network. Occupying a single slot in the SpectraComm Shelf, the SC 553 supports T1 and FT1 services from 56 kbps to a full 1.544 Mbps. Network interface rates may be selected as multiples of either 56 kbps or 64 kbps to the full 1.536 Mbps payload. Connection to data terminal equipment is equally flexible, with support for a V.35 or an optional TIA/EIA-530/422 interface, plus an optional DSX-1 drop and insert interface. A flash memory architecture facilitates downline loading of future firmware upgrades

.
