Canoga Perkins HF101 Hardened 10 Mbps
Ethernet Copper to Fiber Media Converter


Canoga Perkins HF101 Hardened 10 Mbps
Ethernet Copper to Fiber Media Converter

The model HF101 Hardened 10 Mbps Ethernet Copper to Fiber Media Converter is industrial strength all the way.  Rugged packaging extended temperature capability, choice of AC and DC power and ease-of-use are the primary characteristics of this flexible product. Convert and transmit data between 10BaseT unshielded twisted pair (UTP) and 10BaseFL fiber optic cables for media flexibility in new or expanding 10 Mbps Ethernet networks. The unit is fully compliant with the Ethernet version 1.0 / 2.0 specifications and the IEEE 802.3 standards. The HF101 is also energy efficient, consuming only 1.5 watts in use.
The HF101 Hardened 10 Mbps Ethernet Copper to Fiber Media Converter features a sealed metal case, which is also used to dissipate heat. The HF101 requires no airflow for cooling so it easily resists dust, dirt, moisture, smoke, insects and protects the unit internals in case of fire. A selection of external AC or internal DC power options are available to fit virtually every requirement. The ambient temperature rating for the rugged HF101 is 40C to +75C depending on the power source used.  The model HF101 Hardened 10 Mbps Ethernet Copper Media Converter is designed to provide reliable, trouble free operation in harsh industrial and outdoor applications environments. The high-strength fabricated metal packaging shields against
Radio Frequency Interference (RFI) and Electromagnetic Interference (EMI).  The HF101 is backed by a full three-year factory return
warranty.

Canoga Perkins HF101 Hardened 10 Mbps Ethernet Copper to Fiber Media Converter

Hardened for Industrial, Plenum and Outdoor Applications
AC or DC Powered with Choice of Temperature Range
Cross Over Swtich on RJ-45 Port
Visual Status Information Provided by Two Sets of LEDs for Any
Angle Easy Viewing
Sealed Metal Enclosure Requires No Airflow for Cooling
